Gphone Clock (Dam Clock V1.0) sử dụng GLCD 128×64 trong máy bàn không dây Homephone của Viettel và máy Gphone.
Sau khi tháo ra thì ngoài số mã PCB-S68063-1 V02 thì không có thêm thông tin gì khác, lên mạng tìm thì không thấy bất cứ tài liệu datasheet gì nói về con này.
Rất may mình đã tìm được thư viện giao tiếp và sơ đồ chân của Vũ Văn Thái kèm theo bản test mà mình đã đăng lần trước và thấy các hàm đọc, ghi,hiển thị dữ liệu cũng na ná như 1 số dòng LCD khác nên mình quyết định chinh phục em nó cho bằng được.
Sau vài ngày tìm hiểu về cái LCD này mình quyết định cho ra sản phẩm Gphone Clock (Dam Clock V1.0)
Xem thêm:
- Đồng hồ thời gian thực (Read Time Clock – DS1307) sử dụng Arduino
- Đồng hồ số hiển thị trên LED 7 đoạn dùng 89S52 và DS1307
- Hiển thị thời gian thực (RTC DS1307) lên LCD16x2 bằng giao tiếp I2C trong môi trường Arduino
Tuy rằng còn nhiều chức năng thiếu : Báo thức, remote , bật tắt đèn nền … nhưng mình thấy khá hài lòng vì tính ĐỘC và chưa đụng hàng với bất kỳ sản phẩm nào.
Mình cũng quyết định chia sẻ full code C bản Gphone Clock (Dam Clock V1.0) này để anh em nghiên cứu .
Hy vọng rằng anh em có ai share hoặc thương mại thì cũng bớt ra 1 vài dòng chót cho tác giả để mình thấy công sức của mình bỏ ra là hoàn toàn xứng đáng…Xin cảm ơn!
Phần cứng
Mục lục
hiện
- Màn hình GLCD máy Homphone/Gphone
- Vi điều khiển AT89S52 / AT89C52
- IC thời gian thực DS1307
- Cảm biến nhiệt độ DS18B20
- Pin + đế pin Cmos
- Tụ gốm, tụ hóa, điện trở, Jack, Jumer …
(Thông số linh kiện có trong file nguyên lý và sơ đồ chân)
Giới thiệu màn hình GLCD 12864 Homephone Viettel hoặc GPhone VNPT
Màn hình GLCD 12864 HOMEPHONE/GPHONE từ điện thoại Viettel hoặc Vinaphone
Xem hướng dẫn sử dụng chi tiết ở đây nhé:
Hướng dẫn sử dụng glcd ST7565 homephone và chia sẻ thư viện
- Sử dụng IC điều khiển ST7565
- Điện áp: 3,3 – 5,5 VDC (Không khuyến khích sử dụng 5V)
- Kích thước viền ngoài: 60 x 90.5 x 10 mm
- Kích thước màn hình: 70 x 47 mm.
- Độ phân giải: 128px x 64px
GLCD của máy điện thoại không dây Gphone do hãng ZTE sản xuất theo đơn đặt hàng của VNPT.
Ưu điểm của LCD này là đẹp, rẻ có thể đi nhặt đồng nát hoặc xin được, vì giá những con GLCD trên thị trường cũng khá khó kiếm
GLCD có đèn nền mầu trắng hoặc màu vàng sẫm tùy đời máy Gphone
Giao tiếp SPI 4 line tiết kiệm chân MCU, điện áp hoạt động theo mình dò được khoảng 2.2-3.3V (2.5V) và các tính năng khác mình có nêu rõ trong ghi chú Code.
Điều đáng nói ở đây là tài liệu về con GLCD này là không có trên mạng lên việc xác định chân cẳng hoàn toàn bằng kinh nghiệm và chip driver cũng noname luôn, nhưng thật may là mình đã test thử với con ST7565, ST7567… mà tìm ra tập lệnh tương thích với nó.
Như vậy từ bây giờ các bạn có thể sử dụng nó như một Text LCD 20×8 với bộ font được bạn Lê Đắc Đảm biên soạn sẵn và chế độ Graphic cho những bạn nào thích đồ họa đen trắng 😀
Sau đây là sơ đồ nguyên lý chung cho GLCD: Tất cả các LCD trong máy Gphone đều giống nhau!!!!
Chú ý: Vị trí chân của LCD này khác so với LCD 9 chân như sau
- Serial input data = SDA or SI or DIN or MOSI ( chân 7 của màn hình )
- Serial clock = SCL or SCK or SCLK ( chân 3 của màn hình )
- Data/command select = RS or AO or DC ( chân 4 của màn hình )
- LCD chip reset = RST or REST ( chân 2 của màn hình )
- LCD chip select = CS or CE or SS or EN or SCE ( chân 8 của màn hình )
Màn dùng điện áp <5V nên khi cấp nguồn + cho chân 9 của màn hình từ khoảng 2,5-3,3V hoặc dùng cầu chia áp bằng 2 điện trở 10K.
Nguồn (-) cấp vào chân 1 và 10 của màn hình.
Cấp nguồn cho 2 chân led nền là 5 và 6 của màn hình
Một số tài liệu
Bộ font, thư viện mẫu, hướng dẫn sử dụng bạn có thể tải tại đây:
Phần mềm
- Hiển thị giờ phút giây, này tháng năm dương, âm lịch
- Hiển thị nhiệt độ phòng
- 2 loại font 8x8px và 16x16px
Code Gphone Clock (Dam Clock V1.0) được lập trình trên vi điều khiển AT89S52 / AT89C52. Các bạn chú ý!!!
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310 311 312 313 314 315 316 317 318 319 320 321 322 323 324 325 326 327 328 329 330 331 332 333 334 335 336 337 338 339 340 341 342 343 344 345 346 347 348 349 350 351 352 353 354 355 356 357 358 359 360 361 362 363 364 365 366 367 368 369 370 371 372 373 374 375 376 377 378 379 380 381 382 383 384 385 386 387 388 389 390 391 392 393 394 395 396 397 398 399 400 401 402 403 404 405 406 407 408 409 410 411 412 413 414 415 416 417 418 419 420 421 422 423 424 425 426 427 428 429 430 431 432 433 434 435 436 437 438 439 440 441 442 443 444 445 446 447 448 449 450 451 452 453 454 455 456 457 458 459 460 461 462 463 464 465 466 467 468 469 470 471 472 473 474 475 476 477 478 479 480 481 482 483 484 485 486 487 488 489 490 491 492 493 494 495 496 497 498 499 500 501 502 503 504 505 506 507 508 509 510 511 512 513 514 515 516 517 518 519 520 521 522 523 524 525 526 527 528 529 530 531 532 533 534 535 536 537 538 539 540 541 542 543 544 545 546 547 548 549 550 551 552 553 554 555 556 557 558 559 560 561 562 563 564 565 566 567 568 569 570 571 572 573 574 575 576 577 578 579 580 581 582 583 584 585 586 587 588 589 590 591 592 593 594 595 596 597 598 599 600 601 602 603 604 605 606 607 608 609 610 611 612 613 614 615 616 617 618 619 620 621 622 623 624 625 626 627 628 629 630 631 632 633 634 635 636 637 638 639 640 641 642 643 644 645 646 647 648 649 650 651 652 653 654 655 656 657 658 659 660 661 662 663 664 665 666 667 668 669 670 671 672 673 674 675 676 677 678 679 680 681 682 683 684 685 686 687 688 689 690 691 692 693 694 695 696 697 698 699 700 701 702 703 704 705 706 707 708 709 710 711 712 713 714 715 716 717 718 719 720 721 722 723 724 725 726 727 728 729 730 731 732 733 734 735 736 737 738 739 740 741 742 743 744 745 746 747 748 749 750 751 752 753 754 755 756 757 758 759 760 761 762 763 764 765 766 767 768 769 770 771 772 773 774 775 776 777 778 779 780 781 782 783 784 785 786 787 788 789 790 791 792 793 794 795 796 797 798 799 800 801 802 803 804 805 806 807 808 809 810 811 812 813 814 815 816 817 818 819 820 821 822 823 824 825 826 827 828 829 830 831 832 833 834 835 836 837 838 839 840 841 842 843 844 845 846 847 848 849 850 851 852 853 854 855 856 857 858 859 860 861 862 863 864 865 866 867 868 869 870 |
#include<regx52.h> #include <INTRINS.H> #define uchar unsigned char #define CS P2_3 //Chon chip #define SDA P2_2 //Data SPI #define AO P2_1 //Chot du lieu Command va Data (C/D) #define SCK P2_0 //Clock SPI sbit sda = P3^1; sbit scl = P3^0; sbit menu_key=P3^7; sbit up_key=P3^6; sbit down_key=P3^5; sbit DQ = P1^0; uchar temp1,temp2,temp; unsigned char gio,phut,giay,thang_al,ngay_al,mode = 0; unsigned char time[7]; unsigned char code font[][8] ={ {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // ' ' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '!' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '"' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '#' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '$' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '%' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '&' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // ''' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '(' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // ')' {0x00,0x0C,0x1E,0x12,0x12,0x1E,0x0C,0x00}, // '*' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '+' {0x00,0x80,0xE0,0x60,0x00,0x00,0x00, 0x00}, // ',' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '-' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '.' {0x40,0x60,0x30,0x18,0x0C,0x06,0x02,0x00}, // '/' {0x3C,0x7E,0x52,0x4A,0x46,0x7E,0x3C,0x00}, // '0' {0x00,0x44,0x44,0x7E,0x7E,0x40,0x40,0x00}, // '1' {0x44,0x66,0x72,0x52,0x52,0x5E,0x4C,0x00}, // '2' {0x24,0x66,0x42,0x4A,0x4A,0x7E,0x34,0x00}, // '3' {0x10,0x58,0x54,0x7E,0x7E,0x50,0x50,0x00}, // '4' {0x2E,0x6E,0x4A,0x4A,0x4A,0x7A,0x32,0x00}, // '5' {0x3C,0x7E,0x4A,0x4A,0x4A,0x7A,0x32,0x00}, // '6' {0x06,0x06,0x62,0x72,0x1A,0x0E,0x06,0x00}, // '7' {0x34,0x7E,0x4A,0x4A,0x4A,0x7E,0x34,0x00}, // '8' {0x4C,0x5E,0x52,0x52,0x52,0x7E,0x3C,0x00}, // '9' {0x00,0x00,0x66,0x66,0x00,0x00,0x00,0x00}, // ':' {0x00,0x40,0x66,0x26,0x00,0x00,0x00,0x00}, // ';' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '<' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '=' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '>' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '?' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '@' {0x7C,0x7E,0x12,0x12,0x12,0x7E,0x7C,0x00}, // 'A' {0x42,0x7E,0x7E,0x4A,0x4A,0x7E,0x34,0x00}, // 'B' {0x3C,0x7E,0x42,0x42,0x42,0x66,0x24,0x00}, // 'C' {0x42,0x7E,0x7E,0x42,0x42,0x7E,0x3C,0x00}, // 'D' {0x42,0x7E,0x7E,0x4A,0x4A,0x42,0x66,0x00}, // 'E' {0x42,0x7E,0x7E,0x4A,0x0A,0x02,0x06,0x00}, // 'F' {0x3C,0x7E,0x42,0x42,0x52,0x72,0x74,0x00}, // 'G' {0x7E,0x7E,0x08,0x08,0x08,0x7E,0x7E,0x00}, // 'H' {0x00,0x00,0x42,0x7E,0x7E,0x42,0x00,0x00}, // 'I' {0x20,0x60,0x40,0x42,0x7E,0x3E,0x02,0x00}, // 'J' {0x42,0x7E,0x7E,0x08,0x1C,0x76,0x62,0x00}, // 'K' {0x42,0x7E,0x7E,0x42,0x40,0x40,0x60,0x00}, // 'L' {0x7E,0x7C,0x08,0x10,0x08,0x7C,0x7E,0x00}, // 'M' {0x7E,0x7E,0x04,0x18,0x20,0x7E,0x7E,0x00}, // 'N' {0x3C,0x7E,0x42,0x42,0x42,0x7E,0x3C,0x00}, // 'O' {0x42,0x7E,0x7E,0x52,0x12,0x1E,0x0C,0x00}, // 'P' {0x3C,0x7E,0x42,0x42,0x32,0x7E,0x5C,0x00}, // 'Q' {0x42,0x7E,0x7E,0x12,0x32,0x5E,0x4C,0x00}, // 'R' {0x24,0x6E,0x4A,0x5A,0x52,0x76,0x24,0x00}, // 'S' {0x06,0x02,0x42,0x7E,0x7E,0x42,0x06,0x00}, // 'T' {0x3E,0x7E,0x40,0x40,0x40,0x7E,0x3E,0x00}, // 'U' {0x0E,0x1E,0x30,0x60,0x30,0x1E,0x0E,0x00}, // 'V' {0x7E,0x7E,0x20,0x10,0x20,0x7E,0x7E,0x00}, // 'W' {0x42,0x66,0x3C,0x18,0x3C,0x66,0x42,0x00}, // 'X' {0x06,0x0E,0x48,0x78,0x78,0x4E,0x06,0x00}, // 'Y' {0x46,0x62,0x72,0x5A,0x4E,0x46,0x62,0x00}, // 'Z' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '[' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // backslash {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // ']' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '^' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '_' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '`' {0x20,0x74,0x54,0x54,0x3C,0x78,0x40,0x00}, // 'a' {0x42,0x7E,0x3E,0x48,0x48,0x78,0x30,0x00}, // 'b' {0x38,0x7C,0x44,0x44,0x44,0x6C,0x28,0x00}, // 'c' {0x30,0x78,0x48,0x48,0x3E,0x7E,0x40,0x00}, // 'd' {0x38,0x7C,0x54,0x54,0x54,0x5C,0x58,0x00}, // 'e' {0x48,0x7C,0x7E,0x4A,0x02,0x06,0x04,0x00}, // 'f' {0x4C,0x5E,0x52,0x52,0x7C,0x3E,0x02,0x00}, // 'g' {0x42,0x7E,0x7E,0x10,0x08,0x78,0x70,0x00}, // 'h' {0x00,0x00,0x48,0x7A,0x7A,0x40,0x00,0x00}, // 'i' {0x20,0x60,0x40,0x40,0x42,0x7E,0x3E,0x00}, // 'j' {0x42,0x7E,0x7E,0x10,0x38,0x6C,0x44,0x00}, // 'k' {0x00,0x00,0x42,0x7E,0x7E,0x40,0x00,0x00}, // 'l' {0x7C,0x7C,0x08,0x30,0x0C,0x7C,0x78,0x00}, // 'm' {0x7C,0x7C,0x04,0x04,0x04,0x7C,0x78,0x00}, // 'n' {0x38,0x7C,0x44,0x44,0x44,0x7C,0x38,0x00}, // 'o' {0x44,0x7C,0x7C,0x54,0x14,0x1C,0x08,0x00}, // 'p' {0x0C,0x1E,0x12,0x52,0x7C,0x7E,0x42,0x00}, // 'q' {0x44,0x7C,0x78,0x4C,0x04,0x0C,0x08,0x00}, // 'r' {0x48,0x5C,0x54,0x54,0x54,0x74,0x24,0x00}, // 's' {0x04,0x04,0x3E,0x7E,0x44,0x64,0x24,0x00}, // 't' {0x3C,0x7C,0x40,0x40,0x3C,0x7C,0x40,0x00}, // 'u' {0x1C,0x3C,0x60,0x40,0x20,0x3C,0x1C,0x00}, // 'v' {0x3C,0x7C,0x40,0x30,0x40,0x7C,0x3C,0x00}, // 'w' {0x44,0x6C,0x38,0x10,0x38,0x6C,0x44,0x00}, // 'x' {0x4C,0x5C,0x50,0x50,0x50,0x7C,0x3C,0x00}, // 'y' {0x44,0x64,0x74,0x54,0x5C,0x4C,0x44,0x00}, // 'z' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '{' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '|' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // '}' {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // -> {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, // <- }; unsigned char code font_big_1[][8] ={ {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x1E,0x1E,0x1E,0x1E,0x0E,0xFE,0xFE}, {0x00,0xFE,0xFE,0xFE,0xFC,0xF8,0xF0,0xE0}, {0x00,0xF8,0xFC,0xFE,0xFE,0x1E,0x0E,0x0E}, {0xFF,0xFF,0xFF,0xFF,0xFF,0xFF,0xC3,0xC3}, {0x00,0xF8,0xFC,0xFE,0xFE,0x1E,0x0E,0x8E}, {0x00,0x38,0x38,0x38,0x38,0x38,0xFE,0xFE}, {0x00,0x38,0x3C,0x3E,0x3E,0x1E,0x0E,0x0E}, {0x00,0x38,0x3C,0x3E,0x1E,0x0E,0xCE,0xCE}, {0x00,0xFE,0xFE,0xFE,0xFE,0x00,0x00,0x00}, {0x00,0xFE,0xFE,0xFE,0xFE,0xFE,0xCE,0xCE}, {0x00,0xF8,0xFC,0xFE,0xFE,0x9E,0xCE,0xCE}, {0x00,0x1E,0x1E,0x1E,0x1E,0x0E,0x0E,0x0E}, {0x00,0x38,0x7C,0xFE,0xFE,0xDE,0xCE,0xCE}, {0x00,0xF8,0xFC,0xFE,0xFE,0xDE,0x8E,0x8E}, {0x00,0x00,0x00,0x00,0x00,0x18,0x3C,0x3C} }; /////////////////////////////////////////////////////////////////////// unsigned char code font_big_2[][8] ={ {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0xFE,0xFE,0x0E,0x1E,0x1E,0x1E,0x1E,0x00}, {0xC0,0x80,0x00,0xFE,0xFE,0xFE,0xFE,0x00}, {0x0E,0x0E,0x1E,0x3E,0x3E,0x3C,0x38,0x00}, {0xC3,0xC3,0xFF,0xFF,0xFF,0xFF,0xFF,0xFF}, {0xCE,0xEE,0x7E,0xFE,0xFE,0xFC,0xF8,0x00}, {0xFE,0xFE,0x00,0x00,0x00,0x00,0x00,0x00}, {0x0E,0x0E,0x9E,0xFE,0xFE,0xFC,0xF8,0x00}, {0xCE,0xCE,0xDE,0xFE,0xFE,0x7C,0x38,0x00}, {0xFE,0xFE,0xFE,0xFE,0x00,0x00,0x00,0x00}, {0xCE,0xCE,0xCE,0xDE,0xDE,0x9E,0x1E,0x00}, {0xCE,0xCE,0xDE,0xDE,0xDE,0x9C,0x18,0x00}, {0x8E,0xCE,0xEE,0xFE,0xFE,0x7E,0x3E,0x00}, {0xCE,0xCE,0xDE,0xFE,0xFE,0x7C,0x38,0x00}, {0x8E,0x8E,0xDE,0xFE,0xFE,0xFC,0xF8,0x00}, {0x3C,0x3C,0x18,0x00,0x00,0x00,0x00,0x00} }; unsigned char code font_big_3[][8] ={ {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x70,0x7F,0x7F}, {0x00,0x7F,0x7F,0x7F,0x7F,0x00,0x01,0x03}, {0x00,0x1F,0x3F,0x7F,0x7F,0x78,0x70,0x70}, {0xFF,0xFF,0xFF,0xFF,0xFF,0xFF,0x87,0x87}, {0x00,0x1F,0x3F,0x7F,0x7F,0x7E,0x77,0x73}, {0x00,0x70,0x70,0x70,0x70,0x70,0x7F,0x7F}, {0x00,0x60,0x70,0x78,0x78,0x7C,0x7C,0x7E}, {0x00,0x1C,0x3C,0x7C,0x78,0x70,0x71,0x71}, {0x00,0x03,0x07,0x07,0x07,0x07,0x07,0x07}, {0x00,0x1C,0x3D,0x7D,0x7D,0x79,0x71,0x71}, {0x00,0x1F,0x3F,0x7F,0x7F,0x7B,0x71,0x71}, {0x00,0x00,0x00,0x00,0x00,0x00,0x7E,0x7F}, {0x00,0x1E,0x3F,0x7F,0x7F,0x7B,0x71,0x71}, {0x00,0x18,0x39,0x7B,0x7B,0x7B,0x73,0x73}, {0x00,0x00,0x00,0x00,0x00,0x18,0x3C,0x3C} }; unsigned char code font_big_4[][8] ={ {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}, {0x22,0x36,0x3E,0x1C,0x08,0x0E,0x11,0x21}, {0x41,0x8E,0x51,0x21,0x41,0x8A,0x49,0x29}, {0x19,0x0E,0x08,0x08,0x3E,0x3E,0x1C,0x08}, {0x2C,0x24,0x24,0x2C,0x24,0x24,0x2C,0x18}, {0x3C,0x3C,0x2C,0x24,0x24,0x2C,0x24,0x24}, {0x3C,0x7E,0xFF,0xFF,0xFF,0xFF,0x7E,0x3C}, {0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10}, {0x7F,0x7F,0x70,0x00,0x00,0x00,0x00,0x00}, {0x07,0x0F,0x1F,0x3F,0x7F,0x7F,0x7F,0x00}, {0x70,0x70,0x78,0x7C,0x7C,0x3C,0x1C,0x00}, {0x87,0x87,0xFF,0xFF,0xFF,0xFF,0xFF,0xFF}, {0x71,0x70,0x78,0x7F,0x7F,0x3F,0x1F,0x00}, {0x7F,0x7F,0x70,0x70,0x70,0x70,0x70,0x00}, {0x76,0x77,0x73,0x73,0x71,0x71,0x70,0x00}, {0x71,0x71,0x7B,0x7F,0x7F,0x3F,0x1E,0x00}, {0x7F,0x7F,0x7F,0x7F,0x07,0x07,0x07,0x00}, {0x71,0x71,0x7B,0x7F,0x7F,0x3F,0x1F,0x00}, {0x71,0x71,0x7B,0x7F,0x7F,0x3F,0x1F,0x00}, {0x7F,0x7F,0x03,0x01,0x00,0x00,0x00,0x00}, {0x71,0x71,0x7B,0x7F,0x7F,0x3F,0x1E,0x00}, {0x73,0x73,0x7B,0x7F,0x7F,0x3F,0x1F,0x00}, {0x3C,0x3C,0x18,0x00,0x00,0x00,0x00,0x00} }; const unsigned char code lich[]={ 0x1b,0x0c//1999 ,0x11,0x12,0x03,0x04,0x15,0x06,0x07,0x18,0x09,0x1a,0x1b,0x0c ,0x11,0x12,0x03,0x14,0x04,0x15,0x06,0x07,0x18,0x09,0x1a,0x0b,0x1c ,0x11,0x12,0x03,0x14,0x05,0x16,0x07,0x08,0x19,0x0a,0x1b,0x0c ,0x11,0x12,0x03,0x14,0x15,0x06,0x17,0x08,0x09,0x1a,0x0b,0x1c ,0x01,0x12,0x02,0x13,0x14,0x05,0x16,0x07,0x18,0x09,0x1a,0x0b,0x1c ,0x01,0x12,0x03,0x14,0x05,0x16,0x17,0x08,0x19,0x0a,0x1b,0x0c//2005 ,0x11,0x02,0x13,0x04,0x05,0x16,0x17,0x07,0x18,0x19,0x0a,0x1b,0x0c //2006 ,0x11,0x02,0x13,0x04,0x05,0x16,0x07,0x18,0x19,0x1a,0x0b,0x1c ,0x11,0x02,0x03,0x14,0x05,0x06,0x17,0x08,0x19,0x0a,0x1b,0x1c ,0x11,0x12,0x03,0x04,0x15,0x05,0x06,0x17,0x08,0x19,0x0a,0x1b,0x1c ,0x11,0x02,0x13,0x04,0x15,0x06,0x07,0x18,0x09,0x1A,0x0B,0x1C///2010 ,0x11,0x02,0x13,0x14,0x05,0x16,0x07,0x08,0x19,0x0A,0x1B,0x0C ,0x11,0x02,0x13,0x14,0x04,0x15,0x06,0x17,0x08,0x19,0x0a,0x1b,0x0c ,0x11,0x02,0x13,0x04,0x15,0x16,0x07,0x18,0x09,0x1a,0x0b,0x1c ,0x01,0x12,0x03,0x14,0x05,0x16,0x07,0x18,0x19,0x09,0x1a,0x0b,0x1c ,0x01,0x12,0x03,0x04,0x15,0x06,0x17,0x18,0x19,0x0a,0x1b,0x0c ,0x11,0x02,0x13,0x04,0x05,0x16,0x07,0x18,0x19,0x0a,0x1b,0x1c ,0x01,0x12,0x03,0x14,0x05,0x06,0x16,0x07,0x18,0x09,0x1a,0x1b,0x1c//2017 ,0x01,0x12,0x03,0x14,0x05,0x06,0x17,0x08,0x19,0x0a,0x1b,0x1c ,0x11,0x02,0x13,0x04,0x15,0x06,0x07,0x18,0x09,0x0a,0x1b,0x1c ,0x01,0x12,0x13,0x14,0x04,0x15,0x06,0x07,0x18,0x09,0x1a,0x0b,0x1c }; const unsigned int code count_year1[]={ 0,59,413,797,1151,1506,1890,2244, 2628,2983,3337,3721,4075,4429,4813, 5168,5552,5906,6261,6645,6999,7353, 7737,8091,8446,8830,9184,9568,9922, 10276,10660,11015,11369,11753,12108, 12492,12846,13200,13584,13938,14292, 14676,15031,15386,15770,16124,16508, 16862,17216,17600,17954,18309,18693, 19048,19431,19786,20140,20523,20878, 21232,21616,21971,22325,22709,23063, 23447,23801,24156,24540,24894,25249, 25633,25987,26371,26725,27079,27463, 27818,28172,28556,28911,29265,29649, 30003,30387,30741,31096,31480,31834, 32189,32572,32926,33310,33664,34019, 34403,34758,35112,35496,35850,36204,36588}; const unsigned int code count_year[]={ 25 ,391 ,756 ,1121 ,1486 ,1852 ,2217 , 2582 ,2947 ,3313 ,3678 ,4043 ,4408 , 4774 ,5139 ,5504 ,5869 ,6235 ,6600 , 6965 ,7330 ,7696 ,8061 ,8426 ,8791 , 9157 ,9522 ,9887 ,10252 ,10618 , 10983 ,11348 ,11713 ,12079 ,12444 , 12809 ,13174 ,13540 ,13905 ,14270 , 14635 ,15001 ,15366 ,15731 ,16096 , 16462 ,16827 ,17192 ,17557 ,17923 , 18288 ,18653 ,19018 ,19384 ,19749 , 20114 ,20479 ,20845 ,21210 ,21575 , 21940 ,22306 ,22671 ,23036 ,23401 , 23767 ,24132 ,24497 ,24862 ,25228 , 25593 ,25958 ,26323 ,26689 ,27054 , 27419 ,27784 ,28150 ,28515 ,28880 , 29245 ,29611 ,29976 ,30341 ,30706 , 31072 ,31437 ,31802 ,32167 ,32533 , 32898 ,33263 ,33628 ,33994 ,34359 , 34724 ,35089 ,35455 ,35820 ,36185 ,36550 }; const unsigned int code sothang[]={ 0,2,14,27,39,51,64,76,89,101,113, 126,138,150,163,175,188,200,212, 225,237,249,262,274,286,299,311, 324,336,348,361,373,385,398,410, 423,435,447,460,472,484,497,509, 521,534,546,559,571,583,596,608, 620,633,645,658,670,682,695,707, 719,732,744,756,769,781,794,806, 818,831,843,855,868,880,893,905, 917,930,942,954,967,979,991,1004, 1016,1029,1041,1053,1066,1078,1090, 1103,1115,1128,1140,1152,1165,1177, 1189,1202,1214,1226,1239 }; const unsigned int code count_month[] ={0,0,31,59,90,120,151,181,212,243,273,304,334}; const unsigned int code count_month1[]={0,0,31,60,91,121,152,182,213,244,274,305,335}; const unsigned int code nd[]={ 500,485,470,450,430,405,394,384, 368,352,342,332,322,315,308,300, 292,286,275,268,262,256,246,236, 226,216,212,202,188,180,172,165, 156,150,145,140,138,135,130,125, 120,115,110,105,100,98,97,93,90,85 }; unsigned char hex_dec(unsigned char hex){ return((hex>>4)*10 +(hex & 0xf));} unsigned char dec_hex(unsigned char dec){ return(((dec/10) <<4 )+(dec%10));} unsigned int tinhlich(unsigned char ngayduong,thangduong,nam) { unsigned int songay,t5; unsigned char ngayam,thangam; ngayduong = hex_dec(ngayduong); thangduong = hex_dec(thangduong); nam = hex_dec(nam); if(nam%4==0) songay=count_year[nam]+count_month1[thangduong]+ngayduong; else songay=count_year[nam]+count_month[thangduong]+ngayduong; songay--; songay=songay-count_year1[nam]; for(t5=sothang[nam];t5<262;t5++) { if(songay==0)break; if(songay>50000)break; if(lich[t5]>16) { songay=songay-30;} else { songay=songay-29;} } if(songay==0) { if(lich[t5-1]>16) { thangam=lich[t5-1]-16; ngayam=30; } else { thangam=lich[t5-1]; ngayam=29; } } else { if(lich[t5-1]>16) { thangam=lich[t5-1]-16; ngayam=songay+30; } else { thangam=lich[t5-1]; ngayam=songay+29; } } ngayam = dec_hex(ngayam); thangam = dec_hex(thangam); t5= thangam << 8 ; t5 = t5 + ngayam; return(t5); } /////////////////////////////////////////////////////// void delay(unsigned int i) { unsigned int j; while(i-->0) { for(j=0;j<400;j++) { } } } void delay_ms(unsigned int t) { unsigned int x,y; for(x=0; x<t; x++); { for(y=0; y<123; y++); //delay 1ms } } void delay_lcd(unsigned int t){ unsigned int i; unsigned char j; for(i=0;i<t;i++) for(j=0;j<125;j++); } void delay_18B20(unsigned int i) { while(i--); } void lcd_write(unsigned char cd, unsigned char byte){ unsigned char h; CS=0; if(cd)AO=1; else AO=0; for(h=0;h<8;h++){ if(!(byte&0x80))SDA=0; else SDA=1; SCK=0; SCK=1; byte<<=1; } AO=~AO; CS=1; } void lcd_gotoxy(unsigned char x, unsigned char y) { x=x*8; lcd_write(0,(x & 0x0f)); lcd_write(0,((x >> 4) & 0x07)|0x10); lcd_write(0,(y & 0x0f)|0xb0); } void lcd_putchar16_1(char dat) { unsigned char v; if((dat >= 0x20) && (dat <= 0x3a)){ dat=dat-32; for(v=0;v<8;v++) lcd_write(1, font_big_1[dat][v]); } } void lcd_putchar16_2(char dat) { unsigned char v; if((dat >= 0x20) && (dat <= 0x3a)){ dat=dat-32; for(v=0;v<8;v++) lcd_write(1, font_big_2[dat][v]); } } void lcd_putchar16_3(char dat) { unsigned char v; if((dat >= 0x20) && (dat <= 0x3a)){ dat=dat-32; for(v=0;v<8;v++) lcd_write(1, font_big_3[dat][v]); } } void lcd_putchar16_4(char dat) { unsigned char v; if((dat >= 0x20) && (dat <= 0x3a)){ dat=dat-32; for(v=0;v<8;v++) lcd_write(1, font_big_4[dat][v]); } } void lcd_puts_4(char *s) { while(*s) lcd_putchar16_4(*s++); } void lcd_clear() { unsigned char u,w; for(u=0;u<8;u++){ lcd_gotoxy(0,u); for(w=0;w<130;w++) lcd_write(1,0); } lcd_gotoxy(0,0); } void lcd_putchar(char dat) { unsigned char v; if((dat >= 0x20) && (dat <= 0x7f)){ dat=dat-32; for(v=0;v<8;v++) lcd_write(1, font[dat][v]); } } void lcd_putchar_amban(char dat) { unsigned char v; if((dat >= 0x20) && (dat <= 0x7f)){ dat=dat-32; for(v=0;v<8;v++) lcd_write(1, ~font[dat][v]); } } void lcd_puts_amban(char *s) { while(*s) lcd_putchar_amban(*s++); } void lcd_puts(char *s) { while(*s) lcd_putchar(*s++); } void lcd_init() { lcd_write(0,0xE2); //Reset delay_lcd(100); //Delay 100ms lcd_write(0,0xAF); //Display ON, 0xAE - OFF lcd_write(0,0x2F); //Power control lcd_clear(); //Xoa man hinh } void Init_DS18B20(void) { unsigned char x=0; DQ = 1; //DQ reset delay_18B20(8); //Slight delay DQ = 0; //SCM will be pulled down DQ delay_18B20(80); //Accurate delay Greater than 480us DQ = 1; //Pulled the bus delay_18B20(14); x=DQ; //After slight delay is initialized if x = 0 x = 1 is initialized successfully defeat delay_18B20(20); } unsigned char ReadOneChar(void) { uchar i=0; uchar dat = 0; for (i=8;i>0;i--) { DQ = 0; // To the pulse signal dat>>=1; DQ = 1; // To the pulse signal if(DQ) dat|=0x80; delay_18B20(4); } return(dat); } void WriteOneChar(uchar dat) { unsigned char i=0; for (i=8; i>0; i--) { DQ = 0; DQ = dat&0x01; delay_18B20(5); DQ = 1; dat>>=1; } } void ReadTemperature(void) { unsigned char a=0; unsigned char b=0; unsigned char t=0; Init_DS18B20(); WriteOneChar(0xCC); // Skip read serial number column number of operations WriteOneChar(0x44); // Start temperature conversion delay_18B20(100); // this message is wery important Init_DS18B20(); WriteOneChar(0xCC); //Skip read serial number column number of operations WriteOneChar(0xBE); //Read the temperature register, etc. (a total of 9 registers readable) is the temperature of the first two delay_18B20(100); a=ReadOneChar(); //Read the low temperature b=ReadOneChar(); //Read the high temperature temp1=b<<4; temp1+=(a&0xf0)>>4; temp2=a&0x0f; temp=((b*256+a)>>4); //In addition to the current collection temperature of 16 was the actual temperature } ////////////////////////////////////////////////////// void start(void) { scl=1; sda=1; _nop_(); _nop_(); sda=0; _nop_(); scl=0; } void stop(void) { scl=0; _nop_(); sda=0; _nop_(); scl=1; _nop_(); sda=1; } bit write(unsigned char x) { unsigned char i; bit k; for(i=0;i<8;i++) { sda=(x&0x80); scl=1; _nop_(); _nop_(); scl=0; x<<=1; } sda=1; scl=1; _nop_(); _nop_(); k=sda ; scl=0; _nop_(); return k ; } unsigned char read(bit ack) { unsigned char Data,i; sda=1; for(i=0;i<8;i++) { scl=1; Data<<=1; Data=Data|sda; scl=0; } scl =0; sda=ack; scl=1; _nop_(); _nop_(); scl=0; _nop_(); sda = 1; scl = 1; return Data; } void read_ds(void) { int i; start(); write(0xd0); write(0x00); start(); write(0xd1); for(i=0;i<6;i++) time[i] = read(0); time[6] = read(1); stop(); } void write_ds(void) { unsigned char t; start(); write(0xd0); write(0x0); for(t=0;t<7;t++) write(time[t]); stop(); } void am_lich (bit k) { unsigned int t; if((time[2]==0 & time[1] ==0 & time[0] < 3) | (k==1) ) //Tinh lich 00h00p03s { t = tinhlich(time[4],time[5],time[6]); ngay_al=t & 0xff; thang_al= t >> 8; }; } unsigned char tang(unsigned char bcd,unsigned char min,unsigned char max) { if(bcd>=max) bcd = min; else if ((bcd& 0xf)==9) bcd = bcd + 0x10 - 0x9; else bcd++; return bcd; } unsigned char giam(unsigned char bcd,unsigned char min,unsigned char max) { if(bcd<=min) bcd = max; else if ((bcd& 0xf)==0) bcd = bcd - 0x10 + 0x9; else bcd--; return bcd; } void scan_key (void) { static unsigned char l; if(menu_key==0) { delay(10); if(menu_key==0) { while(menu_key==0 & l < 20){ l++; delay(10);}; delay(10); if(l<20) { mode++; if( mode > 7 ) { mode = 0; write_ds(); am_lich (1); } } if(l>=20) { mode = 0; am_lich (1); } } } else if(up_key==0) { delay(10); if(up_key==0) { while(up_key==0 & l < 20){ l++; delay(10);}; delay(10); if(l>=20) { if (mode ==1 ) time[0] = tang(time[0],0 ,0x59); else if(mode ==2 ) time[1] = tang(time[1],0 ,0x59); else if(mode ==3 ) time[2] = tang(time[2],0 ,0x23); else if(mode ==4 ) time[3] = tang(time[3],0x1 ,0x07); else if(mode ==5 ) time[4] = tang(time[4],1 ,0x31); else if(mode ==6 ) time[5] = tang(time[5],1 ,0x12); else if(mode ==7 ) time[6] = tang(time[6],0x1 ,0x20); } if(l<20) { if (mode ==1 ) time[0] = tang(time[0],0 ,0x59); else if(mode ==2 ) time[1] = tang(time[1],0 ,0x59); else if(mode ==3 ) time[2] = tang(time[2],0 ,0x23); else if(mode ==4 ) time[3] = tang(time[3],0x1 ,0x07); else if(mode ==5 ) time[4] = tang(time[4],1 ,0x31); else if(mode ==6 ) time[5] = tang(time[5],1 ,0x12); else if(mode ==7 ) time[6] = tang(time[6],0x1 ,0x20); } } } else if(down_key==0) { delay(10); if(down_key==0) { while(down_key==0 & l < 20){ l++; delay(10);}; delay(10); if(l>=20) { if (mode ==1 ) time[0] = giam(time[0],0 ,0x59); else if(mode ==2 ) time[1] = giam(time[1],0 ,0x59); else if(mode ==3 ) time[2] = giam(time[2],0 ,0x23); else if(mode ==4 ) time[3] = giam(time[3],0x1 ,0x07); else if(mode ==5 ) time[4] = giam(time[4],1 ,0x31); else if(mode ==6 ) time[5] = giam(time[5],1 ,0x12); else if(mode ==7 ) time[6] = giam(time[6],0x1 ,0x20); } if(l<20) { if (mode ==1 ) time[0] = giam(time[0],0 ,0x59); else if(mode ==2 ) time[1] = giam(time[1],0 ,0x59); else if(mode ==3 ) time[2] = giam(time[2],0 ,0x23); else if(mode ==4 ) time[3] = giam(time[3],0x1 ,0x07); else if(mode ==5 ) time[4] = giam(time[4],1 ,0x31); else if(mode ==6 ) time[5] = giam(time[5],1 ,0x12); else if(mode ==7 ) time[6] = giam(time[6],0x1 ,0x20); } } } else l = 0; } void kiem_tra_ds (void) { read_ds(); if(time[0] & 0x80) { time[0] = 0x1; time[1] = 0x40; time[2] = 0x6; time[3] = 0x3; time[4] = 0x1; time[5] = 0x12; time[6] = 0x15; write_ds(); } } void main() { kiem_tra_ds(); am_lich (1); delay_ms(500); lcd_init(); delay_ms(100); lcd_clear(); delay_ms(300); while(1){ if(mode ==0) { read_ds(); ReadTemperature(); am_lich (0); } lcd_gotoxy(0,0); lcd_puts_amban(" DAM CLOCK V1 "); lcd_gotoxy(0,1); lcd_putchar16_1(((time[2]%100)>> 4)+48); lcd_putchar16_2(((time[2]%100)>> 4)+48); lcd_putchar16_1((time[2]& 0xf)+48); lcd_putchar16_2((time[2]& 0xf)+48); lcd_putchar16_1(':'); lcd_putchar16_2(':'); lcd_putchar16_1(((time[1]%100)>> 4)+48); lcd_putchar16_2(((time[1]%100)>> 4)+48); lcd_putchar16_1((time[1]& 0xf)+48); lcd_putchar16_2((time[1]& 0xf)+48); lcd_putchar16_1(':'); lcd_putchar16_2(':'); lcd_putchar16_1(((time[0]%100)>> 4)+48); lcd_putchar16_2(((time[0]%100)>> 4)+48); lcd_putchar16_1((time[0]& 0xf)+48); lcd_putchar16_2((time[0]& 0xf)+48); lcd_gotoxy(0,2); lcd_putchar16_3(((time[2]%100)>> 4)+48); lcd_putchar16_4(((time[2]%100)>> 4)+48); lcd_putchar16_3((time[2]& 0xf)+48); lcd_putchar16_4((time[2]& 0xf)+48); lcd_putchar16_3(':'); lcd_putchar16_4(':'); lcd_putchar16_3(((time[1]%100)>> 4)+48); lcd_putchar16_4(((time[1]%100)>> 4)+48); lcd_putchar16_3((time[1]& 0xf)+48); lcd_putchar16_4((time[1]& 0xf)+48); lcd_putchar16_3(':'); lcd_putchar16_4(':'); lcd_putchar16_3(((time[0]%100)>> 4)+48); lcd_putchar16_4(((time[0]%100)>> 4)+48); lcd_putchar16_3((time[0]& 0xf)+48); lcd_putchar16_4((time[0]& 0xf)+48); lcd_gotoxy(0,4); lcd_puts_amban(" 20"); lcd_gotoxy(3,4); lcd_putchar_amban(((time[6]%100)>> 4)+48); lcd_putchar_amban((time[6]& 0xf)+48); lcd_gotoxy(5,4); lcd_puts_amban(" "); lcd_gotoxy(10,4); lcd_puts_amban(" AL "); lcd_gotoxy(6,4); if(time[3]==0x01) { lcd_putchar16_1('.');} else { lcd_putchar16_1(',');} lcd_gotoxy(7,4); if(time[3]==0x01) { lcd_putchar16_2('.');} else { lcd_putchar16_2(',');} lcd_gotoxy(6,5); if(time[3]==0x01) { lcd_putchar16_3('.');} else { lcd_putchar16_3(',');} lcd_gotoxy(7,5); if(time[3]==0x01) { lcd_putchar16_4('.');} else { lcd_putchar16_4(',');} lcd_gotoxy(8,4); if(time[3]==0x01) { lcd_putchar16_1('-');} else { lcd_putchar16_1((time[3]& 0xf)+48);} lcd_gotoxy(9,4); if(time[3]==0x01) { lcd_putchar16_2('-');} else { lcd_putchar16_2((time[3]& 0xf)+48);} lcd_gotoxy(8,5); if(time[3]==0x01) { lcd_putchar16_3('-');} else { lcd_putchar16_3((time[3]& 0xf)+48);} lcd_gotoxy(9,5); if(time[3]==0x01) { lcd_putchar16_4('-');} else { lcd_putchar16_4((time[3]& 0xf)+48);} lcd_gotoxy(0,5); lcd_putchar(((time[4]%100)>> 4)+48); lcd_putchar((time[4]& 0xf)+48); lcd_putchar('/'); lcd_gotoxy(3,5); lcd_putchar(((time[5]%100)>> 4)+48); lcd_putchar((time[5]& 0xf)+48); lcd_gotoxy(11,5); lcd_putchar(((ngay_al%100)>> 4)+48); lcd_putchar((ngay_al& 0xf)+48); lcd_putchar('/'); lcd_gotoxy(14,5); lcd_putchar((( thang_al%100)>> 4)+48); lcd_putchar(( thang_al& 0xf)+48); lcd_gotoxy(0,6); lcd_puts_4("++++++++++++++++"); if ( mode == 0) { lcd_gotoxy(3,7); lcd_puts_4("*)("); lcd_gotoxy(7,7); lcd_putchar(((temp1%100)/10)+48); lcd_putchar((temp1%10)+48); lcd_putchar(','); lcd_putchar(((temp2%100)/10)+48); lcd_puts("*C "); } else if ( mode == 1) { lcd_gotoxy(3,7); lcd_puts("SET Giay ");} else if ( mode == 2) { lcd_gotoxy(3,7); lcd_puts("SET Phut ");} else if ( mode == 3) { lcd_gotoxy(3,7); lcd_puts("SET Gio ");} else if ( mode == 4) { lcd_gotoxy(3,7); lcd_puts("SET Thu ");} else if ( mode == 5) { lcd_gotoxy(3,7); lcd_puts("SET Ngay "); am_lich (1);} else if ( mode == 6) { lcd_gotoxy(3,7); lcd_puts("SET Thang "); am_lich (1);} else if ( mode == 7) { lcd_gotoxy(3,7); lcd_puts("SET Nam "); am_lich (1);} delay_ms(200); scan_key(); } } |
Code Main chính
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 303 304 305 306 307 308 309 310 311 312 313 314 315 316 317 318 319 320 321 322 323 324 325 326 327 328 329 330 331 332 333 334 335 336 337 338 339 340 341 342 343 344 345 346 347 348 349 350 351 352 353 354 355 356 357 358 359 360 361 362 363 364 365 366 367 368 369 370 371 372 373 374 375 376 377 378 379 380 381 382 383 384 385 386 387 388 389 390 391 392 393 394 395 396 397 398 399 400 401 402 403 404 405 406 407 408 409 410 411 412 413 414 415 416 417 418 419 420 421 422 423 424 425 426 427 428 429 430 431 432 |
#include<regx52.h> #include <INTRINS.H> #include"lib\Fonts.c" #include"lib\LCDG_S68063.c" #include"Amlich.c" //#include"Key.c" #include"Ds18b20.h" sbit sda = P3^0; // SDA sbit scl = P3^1; // SCL sbit menu_key=P3^7; sbit up_key=P3^6; sbit down_key=P3^5; unsigned char gio,phut,giay,thang_al,ngay_al,mode = 0; unsigned char time[7]; /////////////////////////////////////////////////////// void delay(unsigned int i) {unsigned int j; while(i-->0) { for(j=0;j<400;j++) { } } } void delay_ms(unsigned int t) { unsigned int x,y; for(x=0; x<t; x++); { for(y=0; y<123; y++); //delay 1ms } } /*void delay(unsigned int i) {unsigned int j; while(i-->0) { for(j=0;j<400;j++) { } } } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// void nop(void) { unsigned int j=3; while(j-->0) { } }*/ //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// // CAC CHUONG TRINH CON GIAO TIEP VOI RTC // //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// void start(void) { scl=1; sda=1; _nop_(); _nop_(); sda=0; _nop_(); scl=0; } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// void stop(void) //dk stop: 1 su cdoi trang thai tu muc thap len cao tren duong sda trong khi duong { // slc dang o muc cao scl=0; _nop_(); sda=0; _nop_(); scl=1; _nop_(); sda=1; } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// bit write(unsigned char x) { unsigned char i; bit k; for(i=0;i<8;i++) { sda=(x&0x80);//? 1:0; //dua bit du lieu ra chan SDA scl=1; _nop_(); _nop_(); scl=0; x<<=1; //bit co trong so lon hon dc truyen truoc } sda=1; scl=1; //nhan bit ACK tu SLAVER bao hieu ket thuc mot byte du lieu _nop_(); _nop_(); k=sda ; // nhan gia tri ACK scl=0; _nop_(); return k ; } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// unsigned char read(bit ack) { unsigned char Data,i; sda=1; for(i=0;i<8;i++) // nhan vao 8 bit { scl=1; Data<<=1; Data=Data|sda; scl=0; } scl =0; sda=ack;//master gui bit ACK scl=1; //master nhan/gui bit du lieu(sda) khi scl o muc cao _nop_(); _nop_(); scl=0; _nop_();//du lieu(sda) thay doi khi scl muc thap/ sda = 1; scl = 1; return Data;//tra gia tri cho ham } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// void read_ds(void) { int i; start(); write(0xd0); write(0x00); start(); write(0xd1); for(i=0;i<6;i++) time[i] = read(0); time[6] = read(1); stop(); } //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// void write_ds(void) { unsigned char t; start(); write(0xd0); write(0x0); for(t=0;t<7;t++) write(time[t]); stop(); } /**********************************************************************************/ //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// // CHUONG TRINH CON THUC HIEN TINH AM LICH // //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// void am_lich (bit k) { unsigned int t; if((time[2]==0 & time[1] ==0 & time[0] < 3) | (k==1) ) //Tinh lich 00h00p03s { t = tinhlich(time[4],time[5],time[6]); ngay_al=t & 0xff; thang_al= t >> 8; }; }//~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// // CHUONG TRINH CON THUC HIEN VIEC CAI DAT NGAY GIO, THANG NAM // //~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~// unsigned char tang(unsigned char bcd,unsigned char min,unsigned char max)// tang so bcd lên 1 don vi { // chinh tang so bcd len 1 trong gioi han min,max if(bcd>=max) bcd = min; else if ((bcd& 0xf)==9) bcd = bcd + 0x10 - 0x9; // neu hang don vi = 9 thi tang hang chuc len 1 else bcd++; return bcd; } unsigned char giam(unsigned char bcd,unsigned char min,unsigned char max)// giam so bcd xuong 1 don vi { // giam so bcd di 1 if(bcd<=min) bcd = max; else if ((bcd& 0xf)==0) bcd = bcd - 0x10 + 0x9; // neu hang don vi = 9 thi tang hang chuc len 1 else bcd--; return bcd; } //======================================================================= void scan_key (void) { static unsigned char l; if(menu_key==0) // nut menu { delay(10); if(menu_key==0) { while(menu_key==0 & l < 20){ l++; delay(10);}; delay(10); if(l<20) // Nhan de vao cai dat { mode++; if( mode > 7 ) { mode = 0; write_ds(); am_lich (1); } } if(l>=20) // O cai dat nhan giu thi se thoat vaf khong luu { mode = 0; am_lich (1); } } } ///////////////////////////////////////////////////////////////////// else if(up_key==0) // nut down { delay(10); if(up_key==0) { while(up_key==0 & l < 20){ l++; delay(10);}; delay(10); if(l>=20) // Nhan giu de tang gia tri cai dat { if (mode ==1 ) time[0] = tang(time[0],0 ,0x59);// tang giay else if(mode ==2 ) time[1] = tang(time[1],0 ,0x59);// tang phut else if(mode ==3 ) time[2] = tang(time[2],0 ,0x23);// tang gio else if(mode ==4 ) time[3] = tang(time[3],0x1 ,0x07);// tang thu else if(mode ==5 ) time[4] = tang(time[4],1 ,0x31);// tang ngay else if(mode ==6 ) time[5] = tang(time[5],1 ,0x12);// tang thang else if(mode ==7 ) time[6] = tang(time[6],0x1 ,0x20);// tang nam } if(l<20) // Nhan de tang { if (mode ==1 ) time[0] = tang(time[0],0 ,0x59);// tang giay else if(mode ==2 ) time[1] = tang(time[1],0 ,0x59);// tang phut else if(mode ==3 ) time[2] = tang(time[2],0 ,0x23);// tang gio else if(mode ==4 ) time[3] = tang(time[3],0x1 ,0x07);// tang thu else if(mode ==5 ) time[4] = tang(time[4],1 ,0x31);// tang ngay else if(mode ==6 ) time[5] = tang(time[5],1 ,0x12);// tang thang else if(mode ==7 ) time[6] = tang(time[6],0x1 ,0x20);// tang nam } } } ///////////////////////////////////////////////////////////////////// else if(down_key==0) // nut down { delay(10); if(down_key==0) { while(down_key==0 & l < 20){ l++; delay(10);}; delay(10); if(l>=20) // Nhan giu de tang gia tri cai dat { if (mode ==1 ) time[0] = giam(time[0],0 ,0x59);// giam giay else if(mode ==2 ) time[1] = giam(time[1],0 ,0x59);// giam phut else if(mode ==3 ) time[2] = giam(time[2],0 ,0x23);// giam gio else if(mode ==4 ) time[3] = giam(time[3],0x1 ,0x07);// giam thu else if(mode ==5 ) time[4] = giam(time[4],1 ,0x31);// giam ngay else if(mode ==6 ) time[5] = giam(time[5],1 ,0x12);// giam thang else if(mode ==7 ) time[6] = giam(time[6],0x1 ,0x20);// giam nam } if(l<20) // Nhan de tang { if (mode ==1 ) time[0] = giam(time[0],0 ,0x59);// giam giay else if(mode ==2 ) time[1] = giam(time[1],0 ,0x59);// giam phut else if(mode ==3 ) time[2] = giam(time[2],0 ,0x23);// giam gio else if(mode ==4 ) time[3] = giam(time[3],0x1 ,0x07);// giam thu else if(mode ==5 ) time[4] = giam(time[4],1 ,0x31);// giam ngay else if(mode ==6 ) time[5] = giam(time[5],1 ,0x12);// giam thang else if(mode ==7 ) time[6] = giam(time[6],0x1 ,0x20);// giam nam } } } else l = 0; } //======================================================================= void kiem_tra_ds (void) { read_ds(); if(time[0] & 0x80) // kiem tra xem ds1307 co chay khong { time[0] = 0x1; time[1] = 0x40; time[2] = 0x6; time[3] = 0x3; time[4] = 0x1; time[5] = 0x12; time[6] = 0x15; write_ds(); } } //==================================================================== void main() //Chuong trinh chinh { kiem_tra_ds(); am_lich (1); delay_ms(500); lcd_init(); delay_ms(100); lcd_clear(); delay_ms(300); while(1){ if(mode ==0) { read_ds(); ReadTemperature(); am_lich (0); } lcd_gotoxy(0,0); lcd_puts_amban(" DAM CLOCK V1 "); ///////////////////////////////////////////////////////////////// lcd_gotoxy(0,1); lcd_putchar16_1(((time[2]%100)>> 4)+48); //Chuc lcd_putchar16_2(((time[2]%100)>> 4)+48); //Chuc lcd_putchar16_1((time[2]& 0xf)+48); //Don vi lcd_putchar16_2((time[2]& 0xf)+48); //Don vi lcd_putchar16_1(':'); //Don vi lcd_putchar16_2(':'); //Don vi lcd_putchar16_1(((time[1]%100)>> 4)+48); //Chuc lcd_putchar16_2(((time[1]%100)>> 4)+48); //Chuc lcd_putchar16_1((time[1]& 0xf)+48); //Don vi lcd_putchar16_2((time[1]& 0xf)+48); //Don vi lcd_putchar16_1(':'); //Don vi lcd_putchar16_2(':'); //Don vi lcd_putchar16_1(((time[0]%100)>> 4)+48); //Chuc lcd_putchar16_2(((time[0]%100)>> 4)+48); //Chuc lcd_putchar16_1((time[0]& 0xf)+48); //Don vi lcd_putchar16_2((time[0]& 0xf)+48); //Don vi lcd_gotoxy(0,2); lcd_putchar16_3(((time[2]%100)>> 4)+48); //Chuc lcd_putchar16_4(((time[2]%100)>> 4)+48); //Chuc lcd_putchar16_3((time[2]& 0xf)+48); //Don vi lcd_putchar16_4((time[2]& 0xf)+48); //Don vi lcd_putchar16_3(':'); //Don vi lcd_putchar16_4(':'); //Don vi lcd_putchar16_3(((time[1]%100)>> 4)+48); //Chuc lcd_putchar16_4(((time[1]%100)>> 4)+48); //Chuc lcd_putchar16_3((time[1]& 0xf)+48); //Don vi lcd_putchar16_4((time[1]& 0xf)+48); //Don vi lcd_putchar16_3(':'); //Don vi lcd_putchar16_4(':'); //Don vi lcd_putchar16_3(((time[0]%100)>> 4)+48); //Chuc lcd_putchar16_4(((time[0]%100)>> 4)+48); //Chuc lcd_putchar16_3((time[0]& 0xf)+48); //Don vi lcd_putchar16_4((time[0]& 0xf)+48); //Don vi //////////////////////////////////////////////////////////////////// lcd_gotoxy(0,4); lcd_puts_amban(" 20"); lcd_gotoxy(3,4); lcd_putchar_amban(((time[6]%100)>> 4)+48); //Chuc lcd_putchar_amban((time[6]& 0xf)+48); //Don vi lcd_gotoxy(5,4); lcd_puts_amban(" "); lcd_gotoxy(10,4); lcd_puts_amban(" AL "); lcd_gotoxy(6,4); if(time[3]==0x01) { lcd_putchar16_1('.');} // Chu C else { lcd_putchar16_1(',');} // Chu T lcd_gotoxy(7,4); if(time[3]==0x01) { lcd_putchar16_2('.');} // Chu C else { lcd_putchar16_2(',');} // Chu T lcd_gotoxy(6,5); if(time[3]==0x01) { lcd_putchar16_3('.');} // Chu N else { lcd_putchar16_3(',');} // Chu T lcd_gotoxy(7,5); if(time[3]==0x01) { lcd_putchar16_4('.');} // Chu N else { lcd_putchar16_4(',');} // Chu T lcd_gotoxy(8,4); if(time[3]==0x01) { lcd_putchar16_1('-');} // Chu N else { lcd_putchar16_1((time[3]& 0xf)+48);} // Chu THU lcd_gotoxy(9,4); if(time[3]==0x01) { lcd_putchar16_2('-');} // Chu N else { lcd_putchar16_2((time[3]& 0xf)+48);} // Chu THU lcd_gotoxy(8,5); if(time[3]==0x01) { lcd_putchar16_3('-');} // Chu N else { lcd_putchar16_3((time[3]& 0xf)+48);} // Chu THU lcd_gotoxy(9,5); if(time[3]==0x01) { lcd_putchar16_4('-');} // Chu N else { lcd_putchar16_4((time[3]& 0xf)+48);} // Chu THU ///////////////////////////////////////////////////////////////////// lcd_gotoxy(0,5); // ngay dl lcd_putchar(((time[4]%100)>> 4)+48); //Chuc lcd_putchar((time[4]& 0xf)+48); //Don vi lcd_putchar('/'); lcd_gotoxy(3,5); lcd_putchar(((time[5]%100)>> 4)+48); //Chuc lcd_putchar((time[5]& 0xf)+48); //Don vi lcd_gotoxy(11,5); lcd_putchar(((ngay_al%100)>> 4)+48); //Chuc lcd_putchar((ngay_al& 0xf)+48); //Don vi lcd_putchar('/'); lcd_gotoxy(14,5); lcd_putchar((( thang_al%100)>> 4)+48); //Chuc lcd_putchar(( thang_al& 0xf)+48); //Don vi //////////////////////////////////////////////////////////////////// lcd_gotoxy(0,6); lcd_puts_4("++++++++++++++++"); /////////////////////// nhiet do ///////////////////////// if ( mode == 0) { lcd_gotoxy(3,7); lcd_puts_4("*)("); lcd_gotoxy(7,7); lcd_putchar(((temp1%100)/10)+48); //Chuc lcd_putchar((temp1%10)+48); //Don vi lcd_putchar(','); lcd_putchar(((temp2%100)/10)+48); //Chuc lcd_puts("*C "); } else if ( mode == 1) { lcd_gotoxy(3,7); lcd_puts("SET Giay ");} else if ( mode == 2) { lcd_gotoxy(3,7); lcd_puts("SET Phut ");} else if ( mode == 3) { lcd_gotoxy(3,7); lcd_puts("SET Gio ");} else if ( mode == 4) { lcd_gotoxy(3,7); lcd_puts("SET Thu ");} else if ( mode == 5) { lcd_gotoxy(3,7); lcd_puts("SET Ngay "); am_lich (1);} else if ( mode == 6) { lcd_gotoxy(3,7); lcd_puts("SET Thang "); am_lich (1);} else if ( mode == 7) { lcd_gotoxy(3,7); lcd_puts("SET Nam "); am_lich (1);} delay_ms(200); //////////////////////////////////////////////////////////////////// scan_key(); } } |
Cài đặt
- Nhấn phím menu ( P3.7 ) để vào chế độ cài đặt, nhấn up hoặc down để tăng giảm giá trị, khi cài xong Năm nhấn menu lần nữa thì sẽ thoát menu cài đặt về màn hình chính và lưu lại. Nếu đang cài các giá trị mà không muốn cài nữa thì nhấn giữ nút Menu, mạch sẽ trở về màn hình chính và không lưu cài đặt
- Phím up,down khi cài đặt có thể nhấn giữ để tăng giá trị nhanh hơn.
Tải Phiên Bản V1.0 – Full Code
File nén gồm code hex, full code C, file nguyên lý và sơ đồ chân để vẽ mạch in, hiện tại mình đang dùng board nên chưa có file mạch in, mọi người chịu khó vẽ lại vậy.
Muốn mở mạch nguyên lý (File mô phỏng) hãy sử dụng phần mềm Proteus 7.8 (Bấm vào để tải)
GLCD HOMEPHONE CLOCK V1FW0 BY LEDACDAM
Hoặc
Tải Phiên Bản V1.1 – File Hex
- Thêm còi báo đúng giờ từ 21 – 6h
- Hẹn giờ
- Đổi dấu ngát ngày
- Hiển thị ngày lễ tết trong năm
GLCD CLOCK HOMEPHONE V1FW1 BY LEDACDAM
Hoặc
Video Demo Gphone Clock ( Dam Clock V1.0 )
Nguồn: Damclock
